Transmission | Manual |
Clutch | Multiplate assist and slipper clutch |
Gearbox | 6-speed |
Transmission Type | Chain (final drive) |
Chain Type | 2.379:1 |
Gear Ratios 1st | 10.169:1 |
Gear Ratios 2nd | 6.933:1 |
Gear Ratios 3rd | 5.151:1 |
Gear Ratios 4th | 4.105:1 |
Gear Ratios 5th | 3.508:1 |
Gear Ratios 6th | 3.017:1 |
Front Suspension | Double A-Arm |
Rear Suspension | Independent Double A-Arm |
Front Travel | 7.6 in (193 mm) |
Rear Travel | 7.9 in (201 mm) |
Front Shocks | Walker Evans Velocity Series Shocks |
Rear Shocks | Walker Evans Velocity Series Shocks |
Front Braking System | Dual Hydraulic Disc |
Rear Braking System | Hydraulic Disc |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Wheels | Steel |
Front Tire | 24/8-12 |
Rear Tire | 24/10-12 |
Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
Overall Vehicle Size | 43.7" w x 80.1" l x 46.7" h |
Rake / Trail | 24° / 4" |
Wheelbase | 55.1 in (400 mm) |
Seat Height | 32.1 in (815 mm) |
Ground Clearance | 5.1 in (130 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Fuel Capacity | 4.2 gal (15.9 L) |
Storage Capacity | 10.6 gal (40 L) |
Towing Capacity | 680 lbs (1,500 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (82 kg) |
Seating Capacity | 0 |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Bed Capacity | 900 pounds |
Payload Capacity | 220 lbs (485 kg) |
Box Capacity | 1000 lbs (454 kg) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Hitch Capacity | 1,350 lb (612 kg) |
Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage, 6 Gal (23 L) Rear Storage, Toolless Removable Passenger Seat |
Dry Weight | 879 lbs (399 kg) |
Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Magneto | 850-W |
Warranty | 12 / Limited |
Steering | Tilt: Standard |
Features | Front and Rear A-Arm Guards, Front Trail Bumper, Front and Rear Rack Extender, Painted Plastics |
Lighting | LED POD High Beam, LED Low Beam Headlights, Dual LED Brake Lights/Tail Lights |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
Cage Type | Dual-phase 980 steel |
